Description
Hubbell 69JF109243R (034-0097) Pressure Switch, 1-Port, 90/120 PSI, with Unloader Valve.
If your pressure switch is leaking out of the small bleeder valve on the side (or underneath) of the switch after the unit shuts off, order a tank check valve instead, your pressure switch is okay.
Specifications
- OEM switch
- 90/120 PSI
- 1-port manifold (1/4" female NPT)
- 1/4" compression Unloader Valve
- On/off lever switch
Product Fitment
-
Coleman Powermate Sanborn P0502010, CP0502010 Air Compressor Manifold Parts -
Coleman Powermate Sanborn 165B500,104C200, 20E20PC, 30E25PC, 30EM20PC, 109C300, 109C400 Portable Single-Stage Oil-Bath electric Air Compressor Parts -
Coleman Powermate Sanborn V5046049 Stationary Two-Stage Electric Air Compressor Parts -
Coleman Powermate Sanborn C05Z080V2A154 Stationary Two-Stage Electric Air Compressor Parts -
Coleman Powermate Sanborn P0302013, P3001113, P0502013, P0502513 Air Compressor Parts
Old Part Numbers: 034-0097
