Air Compressor Electric Motors
Choosing the right motor for your air compressor is crucial to ensure optimal performance and longevity. Master Tool Repair carries a wide variety of replacement electric motors. Whether you need power, efficiency, or reliability, our selection of air compressor motors has you covered. Find motors for different horsepower, size, and voltage requirements so you can get back up and running again.
We also carry electric motors for many specific applications, including HVAC, pool pump, and pedestal fan motors.
Choosing the right motor ensures efficient operation and extends the life of your air compressor. If you need further assistance, feel free to contact us via Chat, at customerservice@mastertoolrepair.com, or call 757-547-8665.
-
2 HP Regal Beloit Electric Motor #1163DD
Price: $236.48Old Part Numbers: E106044, E1106412 HP Regal Beloit electric motor, 115 V. 2 HP SPL COMPRESSOR DUTY ELECTRIC MOTOR, ODP (OPEN DRIP PROOF) FOR DRY INDOOR ENVIRONMENTS 1 PHASE, 56 FRAME, 3450 RPM, 120V/240VAC, 5/8" SHAFT DIAMETER CAPACITOR START AND...Price: $236.48 -
3 HP Century Electric Motor, 115/220V, Single-Phase #018A42
Price: $475.08Century B383 electric motor for air compressors. 3 HP, 115/220V, 3,600 RPM, 5/8" Shaft, 115/220V, 56 Frame. The B383 is a popular 3 HP motor for home and shop air compressors. See Specifications for more details.Specifications Brand:...Price: $475.08 -
2 HP WEG Electric Motor w/ Dual-Voltage Switch, 115/208-230 Volts, Single-Phase #07F92B
Price: $736.44Old Part Numbers: MTRC102 2 HP WEG replacement electric motor for air compressors.Specifications 2 HP 60 Hz Single-Phase 1,735 RPMs 115/208-230 Volts SFA: 17.0/8.70-8.50 Amps 0.875” Shaft size 143/5T Frame Manual overload with reset...Price: $736.44 -
3 HP Electric Motor, 115/208-230 Volts, Single-Phase #07F9D8
Price: $576.843 HP electric motor for air compressors.Specifications 3 HP Single-Phase 60 Hz 115-208/230 Volts Rated Current: 29.4/16.2-14.7 Amps No-load Current: 13.0/6.50 Amps Full Load Torque: 4.52 ft/lbs Capacitor Start/Run Clockwise Rotation Insulation Class...Price: $576.84 -
7.5 HP WEG Electric Motor, 208-230/460 Volts, 3-Phase #07F9E1
Price: $1,151.407.5 HP WEG electric motor for air compressors, 3-Phase, 1,740 RPM. NOTE: Must ship by truck freightSpecifications 7.5 HP 3-Phase 60 Hz 208-230/460 Volts Rated Current: 20.00-18.10/9.03 Amps CCW Rotation Insulation Class F Ambient Temperature:...Price: $1,151.40 -
1.5 HP WEG Electric Motor, 115/230 Volts, Single-Phase #07F929
Price: $569.241-1/2 HP WEG electric motor.Specifications 1.5 HP Single-Phase 60 Hz 115-208/230 Volts Rated Current: 16.80/8.40 Amps Full Load Torque: 4.43 ft/lbs Capacitor Start/Run CCW Rotation Insulation Class B Rigid Base Ambient Temperature: 40°C 1,755...Price: $569.24 -
3 HP Electric Motor, 3-Phase, VT #01B45A
Price: $604.88Old Part Numbers: MC083300AV3 HP, 3-phase Electric Motor.Specifications HP - 3 (RHP) Phase - 3 Shaft Size - 5/8" FLA at 60 Hz - 9.0-7.5/3.9 RPM - 3,500 Service Factor - 1.15 Class Insulation - B Frame - 56Price: $604.88 -
3.7 HP Electric Motor, 230V #05A2DE
Price: $338.26Service Motor, 3.7 RHP, 230V. SpecificationsSpecs: HP: SPL RPM: 3,540 Phase: 1 Hz: 60 Volts: 208-230 Frame: 56 Enclosure: ODP Duty: Continuous Service Factor: 1.0 Code: N Insulation Class: F Full Load Amps (FLA): 17.2 Brg Ball: 6203RZ Extra...Price: $338.26
