Hubbell Pressure Switch, 4-Port, 95/125 PSI, With Unloader Valve #048A91

Hubbell 69JF7LY2C Pressure Switch, 4-Port (1/4" female NPT), 95/125 PSI factory preset with unloader valve.

Replace the pressure switch if the unit doesn't cut on or off at the designated pressure the unit is set for. If the unloader valve is leaking on the side (or underneath) of the switch AFTER the unit shuts off, do not order this part. Order check valve instead.

• OEM Model
• 1/4" compression (Multiposition)
• On/Off Lever Switch
• 4-port Manifold (1/4" female NPT)
• Default factory pressure setting: 95-125 psi
• Minimum Close Cut In: 50 psi
• Maximum Open Cut Out: 145 psi
• Differential Range: 25-33 psi
• Motor HP Max on 115v - 1.5 HP
• Motor HP Max on 230V/1 PH - 2 HP
• Connections: (4) 1/4" NPT female threaded ports

• On/off lever for compressor control
• UL listed and CSA Certified
• CE and CCC approved
• Silver cad-oxide brazed contacts
• NEMA 1 Enclosure
• Built in clamping strain relief
• Rated for 1-phase and 3-phase applications
