H1512FWK #01AFE7
Loading Schematic
Model Numbers: H1512FWK
Repair Parts for the Husky model H1512FWK Portable Oil-Free Direct-Drive Electric Air Compressor
Manuals
Click here to order and download the Owner's Manual
Extras
We have Husky H1512FWKparts here. Whether you need a pressure switch, valve plate assembly or a new piston kit, we have your parts. Husky H1512FWK parts are easy to come by at Master Tool Repair. We have helpful sales team members that can assist you with your repair. We have accessories as well as rebuild kits to keep your pump running like a top. We keep the most popular Husky H1512FWK parts in stock and we can order most other parts in a matter of a few days. To make ordering easier, we have created the ability for you to order parts by simply enlarging the schematic and then using your mouse to hover over the actual part. You will see the part pop up and are able to order by simply choosing the quantity of parts that you need and adding them to your cart. Make sure to keep spare parts on hand so that your down time will be minimal. If compression is low or pump is slow to pressurize, it's probably due to defective Reed Valves in the pump or a worn Piston Ring and/or Cylinder. We have kits available to restore compression to your pump.
-
Cylinder, SP200 / H1512FWK #05C853
Price: $10.26Air compressor cylinder, SP200/H1512FWK. Replace if worn or if you can see light between the compression ring and inner cylinder wall. Also available in the A610101ConRodKit.Price: $10.26 -
Valve Plate Assembly #05C31A
Price: $14.22Air compressor valve plate assembly; includes 2 plates, valves, and middle gasket. Does not include head gasket or cylinder gasket. Poor performance or does air leak out of the intake filter while the unit is running? The valve plate assembly is probably...Price: $14.22 -
Price: $7.78 -
Price: $0.58 -
Double Screw, 3/8" MPT x 1/4" MPT #05C1E3
Price: $3.893/8" MPT x 1/4" MPT fitting from the air compressor regulator to the pressure switch.Price: $3.89 -
Air Compressor Quick Coupling, 1/4" #05C2DC
Price: $10.581/4" body x 1/4" MPT air compressor quick coupling.Price: $10.58 -
Cylinder Plate Gasket #05C723
Price: $1.08Air compressor cylinder plate gasket below the valve plate. Order 2 if need both top and bottom head gaskets.Price: $1.08 -
Regulator w/ Gauge #05C5EE
Price: $20.44Old Part Numbers: AB-9051118Save money by buying our regulator/gauge combo unit!Price: $20.44
