SC46 Air Compressor Pump Replacement, Complete Assembly, Two-Stage, 7.5 to 10 HP #0186A1

(No reviews yet) Write a Review
Shipping:
Calculated at Checkout
  • SC46 Air Compressor Pump Replacement, Complete Assembly, Two-Stage, 7.5 to 10 HP #0186A1
  • SC46 Air Compressor Pump Replacement, Complete Assembly, Two-Stage, 7.5 to 10 HP #0186A1
Price: $1,377.81

Description

SC46 Air Compressor Pump Replacement, Complete Assembly, Two-Stage, 7.5 to 10 HP. Includes flywheel. 34 CFM @ 175 PSI. Usually for start/stop electric motor-powered units. Used on many different branded units, including Sanborn, Coleman Powermate, Saylor Bealle 707, and NAPA.

Need oil? Click here for synthetic and synthetic-blend air compressor oil to keep your compressor running like new for years to come.

View AllClose

Specifications

  • HP Rating: 7.5 - 10 HP
  • Stages: Two-stage, V-Twin
  • Drive: Reciprocating / Oil-Bath
  • CFM Delivery: 34 CFM @ 175 PSI (10 HP)
  • Max PSI: 175 PSI
  • Material of Construction: cast Iron with steel sleeves
  • Flywheel: 19" OD twin "B" groove
  • RPM: 700 / 860
  • Oil Capacity: 2 qts.
  • Weight: 335 lbs.
  • Bolt Pattern:  9.125" front-to-back, 9.625" side-to-side
  • Dimensions (LWH): 19.5" x 27.25" x 18.75"
  • Duty Cycle: 80/20
  • Outlet: 3/4" FPT
  • Warranty: 1 year limited; customer pays freight on any warranty repairs
View AllClose

Product Fitment

Old Part Numbers: 040-0212, 707

View AllClose

0 Reviews

View AllClose

Extra Details

  • Slow Speed (730-860 RPM)
  • Inserted Rods
  • Centrifugal Unloading
  • Suitable for 215T Frame Motor
  • 10 HP Pump (no head unloaders)
  • SC46 2 Stage Industrial Pump Used on C1023E, 103-C45 series, and is a direct replacement for the Saylor Bealle 707.
View AllClose
