HP50 #01A2E0
Loading Schematic
Model Numbers: HP50
Click Here for a parts breakdown
NOTE! The HP50 is the original Pump but is obsolete. The HP51 will retrofit as a replacement with a few modifications. Click on 'Extra Details' tab above for more info!
Specifications
- 37 CFM @ 100 PSI
- 7.5 - 10.0 HP
- Min RPM 700 Max RPM 1000
- Max Pressure 175 PSI
- 19.70" flywheel.
- Bore LP 5.12
- Bore HP 2.76
- Stroke 3.74
- Belt B-2
- Weight 187 lbs.
- 19.7 L x 16.23 W x 28.00 H
- Bolt Footprint 11.42" Side to Side; 9.06" Front to Back
- 72.64 oz. oil capacity
Extra Details
The HP50 Pump is obsolete, but the replacement HP51 can retrofit onto your tank.
