B6000 #01A238

Model Numbers: B6000

Repair Parts for the Coleman Sanborn B6000 Two-Stage Inline Twin-Cylinder Oil-Bath Air Compressor Pump

Specifications

B6000 Pump specs:

• For 5.0 - 7.5 HP applications.
• Two-stage 175 PSI pump
• 24.2 CFM @ 100 PSI w/ 7.5 HP motor.
• Min RPM: 700. Max RPM: 1,400.
• Footprint 7.8" Front to back holes, 9.76" side to side holes.
• Includes Flywheel.
• Order Air Filter Assy separtely!

Extra Details

Torque Specifications:

• Head Bolts: 340-390 in/lbs
• Air Filter Bolts: 165-205 in/lbs
• Aftercooler Bolts: 340-390 in/lbs
• Intercooler Bolts: 200-240 in/lbs
• Conrod Bolts: 200-240 in/lbs
• Bearing End Cap Bolts: 800-100 in/lbs
• Oil Pan Bolts: 70-115 in/lbs
• Flywheel Bolt: 200-390 in/lbs
