K50, K50HU #01A22A
Loading Schematic
Model Numbers: K50, K50HU
Click Here for a quick parts breakdown
Click Here to view K50HU parts
Specifications
Whole pump or parts.Torque specs:
Connecting Rods:217 in lbs. (oil holes facing in)
Roller Bearing carriers:165 in lbs.
Cylinder Bolts:521 in lbs.
Head bolts:694 in lbs. (in X pattern)
For regulators, pressure switches, pressure gauges, drain cocks and accessories, see "Air Compressor Accessories".
-
Valve, Reed HP #07FA03
Price: $14.82Low-Pressure Reed Valve (4 needed). Order VP gaskets as well when installing new valves.Price: $14.82 -
Crankcase Breather, K50 Pump, 3/8" #07F8A9
Price: $24.57Old Part Numbers: 36500300CHCrankcase Breather with O-ring.Price: $24.57 -
Air Compressor Pressure Switch / Manifold Hex Head Pipe Plug, 1/4"-18 NPT #0E52D4
Price: $1.50Old Part Numbers: 3168Air compressor pressure switch/manifold pipe plug, 1/4"-18 male NPT. A very common hex plug used on countless air compressors, this 1/4" NPT countersunk hex plug installs into any fitting or manifold that has an extra 1/4" female...Price: $1.50 -
Filter Element #07FA14
Price: $24.70Air Filter Element (cartridge) only. Replace every time you change your oil, and more often for higher particle environments.Price: $24.70 -
Gasket, Intercooler & Aftercooler #07FA12
Price: $16.88Gasket for aftercooler and right and left intercoolers. Total of three used.Price: $16.88 -
Price: $12.73 -
Price: $51.74 -
Price: $10.45
