332 / 332TV / 332TVX / R Pump #01B070
Loading Schematic
Model Numbers: 332 / 332TV / 332TVX / R Pump
Repair Parts for the Kellogg model 332/332TV/332TVX and Emglo "R" Two-Stage Oil-Bath Reciprocating Air Compressor Pump
Specifications
- Delivers 17.2 cfm @ 175psi (5HP)
- For 3-5 HP motors
- Cast Iron Construction
- Slower Speed 345-668 RPM's for longer life.
- Longer stroke to produce as much as the 335.
- Steel Rods with Automotive Type Inserts and Needle Bearings at Wrist Pins
- Positive Ring Fed Lubrication
- Centrifugal Unloading & Head Unloading
- Bore: 4 3/4 LP & 2 1/2 HP. Stroke: 4"
Click here for Pump dimensions and specs
-
Cone Bearing & Cup for Crankshaft #116256
Price: $94.60Old Part Numbers: 13414, 98846, CK13414-CK98846 Cone Bearing & Cup for Crankshaft (includes one Bearing and Cup).Price: $94.60 -
Kellogg 332/335 Air Compressor Pump Valve Kit #0197BC
Price: $112.47Old Part Numbers: K332VK, K335VKValve Kit includes valve assemblies for air compressor pump. Includes the valve spring and disc kit. If air leaks out of the intake filter or if the compressor just isn't performing like it should, order this kit. A loss...Price: $112.47 -
Kellogg 332 Air Compressor Pump Gasket Kit, 79454 #019693
Price: $52.58Old Part Numbers: K332GKComplete gasket kit for your Kellogg 332 air compressor pump, including oil seal. If the air compressor pump doesn't seem to pressurize as quickly as it should or is leaking in between the head, valve plate, cylinder, or crankcase...Price: $52.58 -
Kellogg 331/332 Piston, High-Pressure, 38238 #022D61
Price: $108.74Old Part Numbers: 38238HP (smaller) Piston only.Price: $108.74 -
Price: $15.04 -
Kellogg 331 / 332 / 340 Oil Feeder Ring #019790
Price: $26.59Old Part Numbers: 17757Kellogg 331 / 332 / 340 air compressor pump oil feeder ring. This important component feeds oil to the shaft bearings. Replace if the pump is bogging down or squealing to ensure proper lubrication.Price: $26.59 -
On Sale
Centrifugal Unloader Valve #0195A9
Now: $25.95Was: $28.97Centrifugal unloader valve for Kellogg/Campbell Hausfeld/Saylor Beall air compressor pumps. Simply remove old valve, install new valve, and adjust. Specifications 1/8" NPT X 5/16" CompNow: $25.95Was: $28.97 -
Kellogg Valve Hold Down Cover, High-Pressure (HP) #0193CC
Price: $55.30Old Part Numbers: 47929Air compressor valve hold down cover for the high-pressure (HP) valves. Note: This hold down cover comes with a hole drilled for the unloader line (from the crankcase).Price: $55.30
